F-14 Tomcat: History Specifications Bureau Numbers Walk-Around Squadrons Photos Books Memorabilia Other Topics: Grumman A/C EXTRA 400 A/C Photos Links Guestbook Credits The Author	AN/ALQ-167 ECM Pod This additional external electronic countermeasures pod system is used for extra protection from enemy surface-to-air missile or anti-aircraft artillery radar. In addition to the F-14s inbuilt devices, the additional Expanded Chaff Adapter for extra chaffs and flares and the AN/ALQ-167 ECM pod are used on high-threat mission over enemy territory. Specifications: Length 130 in Diameter 10 in Suspension 30 in Weight 236 lbs Click on image-icons to view an enlarged photo: All graphics Copyright © Torsten Anft
